High-Speed Wood Panel Flow Coating Machine for Factory Flooring: Durable Finish & Mass Production Coating Line
جزئیات محصول:
| محل منبع: | چین |
| نام تجاری: | OSMANUV |
| گواهی: | ISO9001 |
| شماره مدل: | OSM-LT-1320 |
پرداخت:
| مقدار حداقل تعداد سفارش: | 1 ست |
|---|---|
| قیمت: | negotiable |
| جزئیات بسته بندی: | بسته بندی چوب |
| زمان تحویل: | 40 روز |
| شرایط پرداخت: | t/t |
| قابلیت ارائه: | مذاکره |
|
اطلاعات تکمیلی |
|||
| منبع تغذیه: | 380V/50Hz ، سیستم سه فاز پنج سیم | انتقال جهت: | از چپ به راست |
|---|---|---|---|
| وضعیت: | جدید | ضمانت: | 1 سال |
| نام محصول: | خط تولید پوشش پرده | سرعت خط تولید: | 0-10 متر در دقیقه |
| انتقال گسترده است: | 1320 میلی متر | ||
| برجسته کردن: | wood panel flow coating machine,high-speed curtain coating machine,factory flooring coating line,high-speed curtain coating machine,factory flooring coating line |
||
توضیحات محصول
High-Speed Wood Panel Flow Coating Machine for Factory Flooring: Durable Finish & Mass Production Coating Line
Product Description:
Our high-speed automated flow coating line is engineered for furniture panel, door skin, and laminate flooring manufacturers seeking unparalleled throughput. This system delivers a consistent, high-gloss, or satin finish with exceptional durability, ideal for high-volume production environments. The entire process, from feeding to curing, is seamlessly integrated for maximum efficiency and minimal downtime.
Technical Parameters:
| Parameter Category | Details & Specifications |
|---|---|
| Dimensions | 6000mm L × 2200mm W × 1400mm H |
| Belt Height from Ground | 850-900mm adjustable |
| Total Weight | 2000 kg |
| Coating Width | 1320 mm |
| Processing Thickness | 3-80 mm |
| Minimum Processing Length | 300 mm |
| Conveyor Power | 2.2 kW |
| Oil Pump Power | 2.2 kW |
| Paint Consumption | 60-200 g/m² |
| Paint Tank Capacity | 250 kg |
Application:
Mass production of furniture panels, kitchen cabinets, laminate flooring, door skins, and wall panels.
Feature:
- Ultra-High Speed Coating for maximum output.
- Precision Coating Head for uniform film thickness.
- Energy-Efficient UV Curing System.
- Fully Automated Conveyor System with automated feeding and stacking.
Customization:
We offer extensive customization options including line length, conveyor width, coating tank capacity, and specific curing solutions to match your factory layout and product requirements perfectly.
Support and Services:
Comprehensive package including installation supervision, operator training, remote troubleshooting, and an extensive inventory of spare parts for prompt delivery.
Packing and Shipping:
All modules are crated in heavy-duty wooden frames with waterproof wrapping for sea freight. Professional export packing ensures safe arrival.
FAQ:
- Q: Can this line handle different panel sizes without lengthy changeovers?
A: Yes, the conveyor and coating system are designed for quick width adjustments to accommodate various panel sizes, minimizing downtime.
