High-Efficiency Infrared Drying Line for Furniture Board & Molded Pulp Products - Energy-Saving Thermal Solution
جزئیات محصول:
| محل منبع: | چین |
| نام تجاری: | Osmanuv |
| گواهی: | ISO9001 |
| شماره مدل: | OSM-UV-1320T |
| سند: | 5 Meters IR Drying Machine.pdf |
پرداخت:
| مقدار حداقل تعداد سفارش: | 1 ست |
|---|---|
| قیمت: | negotiable |
| جزئیات بسته بندی: | جعبه چوبی |
| زمان تحویل: | 45 روز |
| شرایط پرداخت: | t/t |
| قابلیت ارائه: | مذاکره |
|
اطلاعات تکمیلی |
|||
| سرعت کمربند نقاله: | 10-30 متر در دقیقه | منبع نور: | نور UV |
|---|---|---|---|
| میز کار: | شناور | برند اینورتر: | اشنایدر |
| اسلحه اسپری: | از تفنگ اسپری اتوماتیک GRACO آمریکایی استفاده کنید | دوام پوشش: | دوام |
| روش پوشش: | کلاهک های پرتاب جوهر DOD | نوع غلتکی: | سیم فلزی |
توضیحات محصول
High-Efficiency Infrared Drying Line for Furniture Board & Molded Pulp Products - Energy-Saving Thermal Solution
Keywords: infrared drying line, furniture board drying, molded pulp dryer, customizable drying system, industrial infrared oven
Composition of Production Line:
Pre-drying infrared module, main infrared drying tunnel, heat circulation system, temperature control cabinet, conveyor belt system, cooling section, PLC control panel
Product Description:
This infrared drying line is specifically designed for rapid and uniform drying of furniture boards (MDF, particleboard) and molded pulp products. It ensures moisture removal with minimal energy consumption and reduced footprint compared to conventional drying methods.
Technical Parameters:
| Parameter | Specification |
|---|---|
| Heating Technology | Medium-wave infrared emitters |
| Temperature Range | 50-400°C (customizable) |
| Belt Width | 600-2000mm (customizable) |
| Drying Speed | 0.5-5 m/min (adjustable) |
| Power Supply | 380V/50Hz/3Phase (configurable) |
| Control System | Siemens PLC + 10" HMI touchscreen |
| Heating Power | 30-200kW (customizable based on capacity) |
Application:
Drying of furniture boards, molded pulp packaging, egg trays, and industrial fiber products.
Customization:
Fully customizable infrared emitter layout, belt width, heating zones, and temperature profiles to match specific product requirements.
Feature:
-
40% energy saving compared to hot air drying
-
Uniform heating without surface overheating
-
Quick response and precise temperature control
-
Minimal maintenance requirements
Support and Services:
Installation supervision, operator training, 24/7 technical support, spare parts supply
Packing and Shipping:
Modular design for easy shipping, weather-proof packaging, FOB/CIF terms available
FAQ:
Q: Can the line handle different product thicknesses?
A: Yes, the temperature and speed are fully customizable for various thicknesses.
