Multi-Substrate Automatic Laminating Machine for Furniture, Calcium Carbonate, and Metal Panels | High-Efficiency Production Line
جزئیات محصول:
| محل منبع: | چین |
| نام تجاری: | Osmanuv |
| گواهی: | CE |
| شماره مدل: | OSM-FM-1320 |
پرداخت:
| مقدار حداقل تعداد سفارش: | 1 ست |
|---|---|
| قیمت: | negotiable |
| جزئیات بسته بندی: | جعبه چوبی |
| زمان تحویل: | 35 روز کاری |
| شرایط پرداخت: | t/t |
| قابلیت ارائه: | مذاکره |
|
اطلاعات تکمیلی |
|||
| بسته بندی: | مورد استاندارد چوبی | غلتک دوز: | 164mm*1450mm |
|---|---|---|---|
| سر بمیر: | قابل تنظیم | اجزای اصلی: | موتور ، موتور |
| کمربند qty: | 1/2/3 | کمربند: | کمربند مش تفلون |
| ضمانت: | 1 سال | روش روکش: | روکش ضامن |
| برجسته کردن: | automatic laminating line for furniture,high-speed film laminating machine,precision coating laminating solution,high-speed film laminating machine,precision coating laminating solution |
||
توضیحات محصول
Multi-Substrate Automatic Laminating Machine for Furniture, Calcium Carbonate, and Metal Panels | High-Efficiency Production Line
Keywords: furniture panel laminating line, automatic coating machine, film laminating equipment, customizable coating system
Composition of Production Line:
Automatic feeding system, precision glue applicator, film unwinding station, hot press laminating unit, UV curing system, cooling section, trimming unit, stacking robot.
Product Description:
This fully automatic laminating line applies protective and decorative films to furniture panels (MDF, particleboard, plywood) with high precision and efficiency, ensuring perfect adhesion and surface quality.
Technical Parameters:
| Parameter | Specification |
|---|---|
| Max. Panel Width | 1300-2500 mm (customizable) |
| Line Speed | 10-30 m/min (adjustable) |
| Glue Application | 50-300 g/m² (customizable) |
| Heating Power | 60-200 kW (configurable) |
| Control System | Siemens PLC + 15" HMI |
| Power Supply | 380V/50Hz/3Phase (customizable) |
| Accuracy | ±0.5 mm |
Application:
Decorative film lamination for furniture panels, door skins, wall panels, and interior decoration materials.
Customization:
Fully customizable panel width, glue type, heating system, and automation level to meet specific production requirements.
Feature:
-
Automatic thickness detection and adjustment
-
Energy-saving heat recovery system
-
Quick-change film rolls design
-
IoT-enabled production monitoring
Support and Services:
Installation supervision, operator training, 24/7 technical support, annual maintenance contracts.
Packing and Shipping:
Export-standard wooden crates, weather-proof packaging, professional logistics coordination.
FAQ:
Q: Can the line handle different panel thicknesses?
A: Yes, the system is customizable for various thicknesses from 2mm to 30mm.
